Tata Wash Equipment - TATA RAGE-X
CONTACT US TO KNOW MORE
The reliable and an attractive Car Wash machine diligent with high technology and top features for the best results.
Tata Rage-X offers a car wash experience that marks an irreplaceable experience of the Ultimate Car Wash to enhance business & its revenue on high front.
The flexible programming of Tata Rage-X facilitates adaptation to individual user needs. Different wash programs can be configured, speeds can be parametrised, chemical products can be dosed, light sign codes can be set, etc.
Tata Rage-X offers a car wash experience that marks an irreplaceable experience of the Ultimate Car Wash to enhance business & its revenue on high front.
The flexible programming of Tata Rage-X facilitates adaptation to individual user needs. Different wash programs can be configured, speeds can be parametrised, chemical products can be dosed, light sign codes can be set, etc.
| Machine Structure | Hot Dip Galvanized 3 mm plates |
| Brush Pressure Sensing | Yes With Relay Control |
| Brushes Material | Soft Foam EVA Brush |
| Vertical Brush | 2 With Sliding System |
| Horizontal Brush | 1 With Rope Wire Drive System |
| Wheel Brush | 2 With Water Spray Nozzle |
| Shampoo | Shampoo Cycle |
| Foam | Foam Cycle |
| Wax | Wax Cycle |
| Dryer | On-board Contour Following Blowers |
| Height | 2.3 m / 7.5 ft |
| Width | 2 m / 6.5 ft |
| Length | 5.2 m / 17 ft |
| Electricity Supply | 415 Voltage 50 Hz 3 Phase with Neutral |
| Max Power Required | 20 HP / 15 KW |
| Control Programming | PLC SIEMENS |
| Control System | HMI Panel 7" Touch Screen Color with process graphic Display |
| Remote Connectivity | Wireless Remote Diagnostics |
| Wheel Guides | Square Pipe Yellow 6mtr with LED |
| Trolley Rails | Rectangular Bar Hot dip Galvanized |
| Water Pump Details | MONOBLOCK PUMP + PRESSURE PUMP |
| Min. Pressure | 8 bar |
| Cable Carrier System | Cable Track Chain |
| Machine Fascia | ABS |
| Body Paint | Auto Painted |
